Building Type:
Warehouse converted to architect’s office

Owner:
Busby Perkins+Will

Location:
1220 Homer Street, Vancouver, BC

Budget: $1,100,000

Completion:
Original – 1946
Rehabilitation – 2000

PROJECT TEAM

Architect:

Busby Perkins+Will
P. Busby, D. Dove, S. Gushe, S. Ockwell

Designlines Ltd.
S. Schou

Structural Engineer:

Glotman Simpson

Skylight:

Fast & Epp

Electrical Engineer:

Flagel Lewandowski
(now Acumen Engineering)

Mechanical Engineer:

Keen Engineering

1220 Homer Street

Busby Perkins+Will / Designlines Ltd.

OTHER SUSTAINABILITY FEATURES & MEASURES


Products & Materials

PHOTO: Busby Perkins+Will

Sandblasted concrete:
Sandblasting can be a low-impact way of retaining the industrial aesthetic of an existing building while providing the benefits of an exposed thermal mass. Acoustics can be problematic with these types of hard, exposed surfaces, but this can be mitigated with the simple intervention of hanging acoustic baffles or soft furnishings.

Ceiling:
While a white-painted ceiling would technically bounce more daylight into the space, the exposed, sandblasted concrete is also used as an aesthetic highlight to the glass, steel and aluminum detailing.

Flooring:
The reception area formally served as an office for the warehouse and was situated lower than the warehouse floor. Busby Perkins+Will raised the floor level to be more accesible from street level.

Recycled content:
Typically used underneath ice rinks, the attractive flooring is made of 100% recycled tires. Busby Perkins+Will clients often request it as a floor finish for all kinds of buildings, despite its ‘usual’ application.

Exposed structure + services:
An exposed structure generally means exposed service ducts, electrical cables and the like. In this case, the fact that the building is naturally ventilated means there is little or no hanging ductwork and noisy fans to muffle and hide behind acoustic panels. However, careful placement of electrical services is essential to maintain aesthetic control over the ceiling. Cutting, drilling and fastening services on and through structural members also requires careful planning to avoid the ceiling falling down.



Other Features & Measures

A live, internet-accessible ‘dashboard’ system displays and tracks water and energy use, which helps with individual and group accountability.
